98-08 Toyota Keyless Entry Remote 4-Button New GQ43VT14T / PN: 89742-AA030

ITEM DESCRIPTION

The keyless entry remote for sale is Brand New Aftermarket Replacement.

Specifications:

• FCC ID: GQ43VT14T

• Frequency: 315 MHz

• Battery: CR2032 (included)

• Buttons: Lock, Unlock, Trunk, Panic (panic button located on back)

• Part Number: 89742-AA030

• Onboard Programming: Yes

Includes:

• 1 Remote Included Only

Fitment:
Compatible with the following vehicles (only for vehicles that originally came without LED on the remote):

• 1999 – 2006 Toyota Camry

• 1998 – 2003 Toyota Solara

• 2003 – 2008 Pontiac Vibe

• 2003 – 2008 Toyota Matrix

• 1998 – 2003 Toyota Sienna

Important Notes:

• This remote is not compatible with dealer-installed keyless entry systems.

• Dealer-installed systems typically have an LED light on the front of the original remote.

• Please verify your original remote FCC ID before purchasing to ensure compatibility.

Step-by-Step Programming Instructions:

1. Start with the key out of the ignition. Driver's door is open, all other doors closed, and driver’s door unlocked.

2. Insert the key into the ignition (Do not turn), then pull it out.

3. Perform these steps within 40 seconds:
   A. Using the power door lock switch on the driver’s door, perform 5 lock/unlock cycles starting with lock. Use an even pace (about 1 cycle per second).
   B. Close, then reopen the driver’s door.

4. Perform these steps within 40 seconds:
   A. Using the power door lock switch, perform 5 lock/unlock cycles starting with lock (same pace as before).
   B. Insert the key into the ignition.
   C. Turn the ignition to ON (Do NOT start), then back to OFF.
   D. Turn the ignition to ON again (Do NOT start), then back to OFF.
   E. Remove the key from the ignition.

5. Within 3 seconds, the power door locks should cycle automatically, indicating successful entry into programming mode. If locks do not cycle, return to Step 1.

6. Perform these steps within 40 seconds for each remote:
   A. Press and hold the Lock and Unlock buttons on the remote simultaneously for 1 second.
   B. Immediately after, press and hold the Lock button by itself for 2 seconds.
   C. Within 3 seconds, the door locks should cycle once indicating successful programming. If locks do not cycle or cycle twice, repeat steps A and B.

7. Close the driver’s door to complete the programming.
